Samsung Flip 2 55" 3840 x 2160 Interactive Display

Panel
Diagonal Size55"

Type60Hz New Edge
Resolution3840*2160 (Landscape)

Brightness(Typ.)350 (without glass), 220 (with glass) nit

Contrast Ratio4000:1 (Typ.)(without glass)

Viewing Angle(H/V)178/178

Response Time(G-to-G)8ms(Typ.)
Operation Hour16/7
Sound
Speaker TypeBuilt in Speaker (10W x 2)
Connectivity
Input
Video(Basic) HDMI 2 (With Tray) HDMI 3

USB(Basic) USB 1 (With Tray) USB 2, USB External (In/Out) 1
Output
Touch Out(Basic) Touch Out 1 (USB Upstream Type), Audio Out 1 (With Tray) Touch Out 2, Audio Out 1, Screen Share(HDMI-Out) 1
INTERNAL SENSOR(Basic) Acceleration sensor (With Tray) Acceleration sensor, NFC
External ControlTouch Input, RS232C thru stereo jack, RJ45(For MDC)
Touch
TypeInGlass™
# of DrawingMulti writing up to 4
Touch Pen TypePassive Pen with magnet
Object Recognition Range2mm/ 4mm / 8mm / 50mm , 1024 Level on Brush Mode
Touch Response Time6.7ms
Power
TypeInternal
Power SupplyAC 100~240V 50/60Hz
Power Consumption
Max[W/h]154

Typical[W/h]80

Rating[W/h]140
Stand-by(Max)0.5
BTU(Max)525.14
Mechanical Specification
Dimension (mm)
Set1297.4(W) x 768.2(H) x 59.9(D)
Package1464(W) x 915(H) x 190(D)
Weight (kg)
Set28.2
Package35.2
ColorLight Gray
VESA Mount (mm)400 x 400
Protection GlassYes
Stand TypeMoving Stand / Wallmount (WMN4277SE)
RotationYes
Power Cable Length3m
AccessoryCover-Jack
Operation
Operating Temperature0  ℃  ~   40   ℃

Humidity10  %  ~   80   %
Feature
Key FeaturesFlip App
Special FeaturesH/W : Super Clear Coating, Temperature Sensor, Pivot Display, Clock Battery(168hrs Clock Keeping), Built in Speaker(10W x 2), WiFi Module Embedded S/W : Flip S/W Flatform : Muse-M (Tizen 5.0)
Internal Player
ProcessorCA72 Quad(1.7GHz)

On-Chip Cache MemoryL1 (I/D) : 32KB / 32KB L2 (Unified) : 1MB

Clock Speed1.7GHz CPU Quad

Main Memory InterfaceLPDDR4 1.6GHz 64bit 2.5GB
Graphics2D & 3D Graphics Engine - Up to 1920x1080. 32bpp - Supports OpenGL ES

Storage (FDM)8GB (2.65GB Occupied by O/S, 5.35GB Available)

MultimediaN/A

IO PortsUSB 2.0
Operating SystemSamsung Proprietary OS(VDLinux)
Certification
SafetyN/A

EMCN/A
Accessory
IncludedPassive Pen(2), Power Cable, Touch Out Cable (USB upstream)
Optional
StandSTN-WM55R

MountWMN4277SE

SpecialtyFlip UX

TrayCY-TF65BRC
Media Player
Media Player
Media PlayerN/A
